Description

Key Features

Built-In Standoff

The 1 inch standoff lifts the post off the concrete, which helps reduce moisture contact at the post end. That matters for deck posts, basement posts, and other structural posts exposed to splash or damp conditions.

Easier Post Alignment

The slotted anchor hole gives you adjustment around the anchor bolt, so you can fine-tune post placement instead of fighting a fixed hole. That saves time when layout is close but not perfect.

ABA66Z for 6×6 Posts

This retrofit post base is sized for nominal 6×6 posts and made from 14 gauge steel with a ZMAX finish. It is a practical choice for deck footings and other top-supported wood-to-concrete connections.

Overview

The Simpson Strong-Tie ABA66Z Adjustable Standoff Post Base is a retrofit post base for attaching a nominal 6×6 wood post to existing concrete. This is a post base designed for post-to-footing connections in decks and other top-supported structures. Model Number ABA66Z. If you are setting structural posts on cured concrete and want a cleaner, more forgiving installation than a fixed base, this is the hardware built for that job.

What makes the ABA66Z useful on the job is the slotted anchor hole in the base. Instead of having one locked-in anchor position, you get some adjustment around the anchor bolt, which makes precise post placement easier. That helps when you are lining up deck framing, patio cover posts, or other supports and need to correct small layout differences without reworking the footing.

The built-in 1 inch standoff is not just a nice detail. It helps meet code requirements for structural posts installed in basements or in areas exposed to weather or water splash, and it helps keep the end of the post off the concrete where moisture tends to sit. For exterior wood construction, that added separation is one of the features that actually matters long term.

On the strength side, the ABA66Z is made from 14 gauge steel with a ZMAX galvanized finish for extra corrosion resistance in exterior and treated-wood applications. Simpson rates this model for increased uplift loads for earthquake or wind loading, with allowable loads listed at 920 for uplift and 11,415 for download in the provided load table for Douglas Fir/Southern Pine conditions. It uses a 5/8 inch anchor diameter and fastens to the post with either (8) 0.162 x 3-1/2 inch nails or approved Strong-Drive SD connector screws.

In practical terms, this Simpson Strong-Tie post base is a strong fit for deck builders, remodelers, and contractors working on wood framing over existing concrete. It is best for decks, patio covers, and similar top-supported structures where you need a wood-to-concrete retrofit connection with some adjustability. It is not recommended for non-top-supported installations such as fences or unbraced carports, because post bases like this do not provide enough resistance to prevent the member from rotating about the base.

Dial In Post Placement on Existing Concrete

This is where the ABA style base earns its keep. When you are retrofitting to cured concrete, the slotted anchor hole gives you room to adjust the post location instead of being stuck with one exact anchor position.

• Designed to attach wood posts to existing concrete
• Slotted base helps fine-tune alignment around the anchor bolt

Keep the Post Off the Concrete

The 1 inch standoff is one of the most important parts of this connector. It helps reduce moisture exposure at the bottom of the post and supports code-driven post separation from the concrete surface.

• 1 inch standoff for structural posts in damp or exposed locations
• Good fit for decks and other top-supported exterior structures

What’s in the Box

• (1) Simpson Strong-Tie ABA66Z adjustable standoff post base

Fasteners are not included. Install with specified nails or approved Strong-Drive SD connector screws.

Key Specifications

Nominal Post Size	6 x 6
Material Gauge	14 ga.
Width (in.)	5 1/2
Length (in.)	5 3/8
Height (in.)	3 1/8
Anchor Diameter (in.)	5/8
Finish	ZMAX galvanized
Allowable Uplift Load	920
Allowable Down Load	11,415
Weight (lbs)	1.6

Compatibility

Post Size

Sized for nominal 6×6 wood posts.

Anchor Requirement

Uses a 5/8 inch anchor diameter for the concrete connection.

Concrete Retrofit Use

Designed for attaching wood posts to existing concrete footings and similar cured concrete supports.

Fastener Options

Install with (8) 0.162 x 3-1/2 inch nails or approved Strong-Drive SD connector screws.

Built For

Deck Building Patio Covers Post-to-Footing Connections Exterior Wood Construction Remodeling General Contracting Wood Framing Retrofit Concrete Work

Pro Tip

When you set your anchor, keep it extending less than 1 inch above the concrete. If it sticks up too far, it can interfere with the ABA66Z standoff and make the post base harder to seat correctly.

Tool Nut’s Take

Tool Nut’s Take

Simpson Strong-Tie ABA66Z Adjustable Standoff Post Base Gets the Important Stuff Right

If you are anchoring a 6×6 post to existing concrete, this is the kind of connector that makes layout easier and gives you the standoff you actually want outdoors.

• Who it’s for: Deck builders, framers, and serious DIYers setting 6×6 posts on cured concrete for top-supported structures.
• Why it stands out: The slot gives you adjustment at the anchor bolt, and the 1 inch standoff helps with moisture management instead of trapping the post on the slab.
• Worth knowing: This is a retrofit post base, not a fix for unsupported post installations. Use the specified fasteners and keep it in the kind of application it was designed for.

Common Questions

• What size post does this base fit? The ABA66Z is sized for a nominal 6×6 wood post.
• Can this be used on existing concrete? Yes. The ABA series is designed to attach wood posts to existing concrete in retrofit applications.
• Does the base help keep the post away from standing moisture? Yes. It has a built-in 1 inch standoff that lifts the post off the concrete surface.
• What fasteners are used at the post? The provided load table lists (8) 0.162 x 3-1/2 inch nails, and Simpson also states the base can be fastened using nails or Strong-Drive SD connector screws.
